Danfoss Mcd5-0089B-t5-g1X-20-cv2 3 Phase Soft Starter 200-525 Vac (Not Working)
Danfoss
Vlt
Soft Starter
Mcd5-0089B-t5-g1X-20-cv2
175G5531
3 Phase, 200-525 Vac, 50/60Hz
0089A, Ac-53B: 3-30: 570, 45Kw (60Hp) 400Vac
S/C Withstand: Type 1 Coordination
Enclosure Rating: Ip 20, Nema 1, Ul Type 1
Pollution Degree: 3
Aux.Terminals: 12-30 Awg, 1.5Mm 2 At Torque 0.5 Nm, 4.5 In-lb
Aux.Contacts: 10A @ 250Vac Of 10%, A300, Ac15 6A@ 250Vac
Power Terminals: 10-1/0 Awg, 6-50 Mm2, At Torque 4 Nm, 2.9 Ft-lbs
Copper Solid Or Stranded 60/75°C Conductors
Made In New Zealand
Weight: 4.940 Kg
