Eaton Sd32X Surge Protection Device 33223312080 32V 400Ma
Eaton Electric Ltd
Crouse-hinds Series
Mtl Surge Technologies
Surge Protection Device
Mtl Surge Protection Device
Sd32X
Sd Series Of Signal Surge Protectors
Working Voltage (Un): 32V
Max. Continuous Operating Voltage (Uc): 36V
Breakdown Voltage Range: 45V-47V
Standby Operating Voltage: Less Than 32V
Rated Load Current: 400Ma
Max. Resistance: 2.2Ω/Line
Max. Line Inductance: 110µH/Line
Max. Surge Current (Imax): 20Ka (8/20µS)
Impulse Current (Limp): 2.8Ka
Imax= 186Ma Li= 220µH Ci= 0µF
Pmax=Pi= 1W (-30°C Less Than Ta Less Than 75°C)
Pmax=Pi= 1.2W (-30°C Less Than Ta Less Than 60°C)
Pmax=Pi= 1.3W (-30°C Less Than Ta Less Than 40°C)
Ru C-gb.Hb07.B.00317/21
Ex Ia Iic T4 Ga
-30°C Ta + T* °C
E220693
250942/H
33223312080
Made In India
Weight: 70 Gm
