Terasaki Ap-20 Air Circuit Breaker 3P 5P3A2B, Pqh9268B1, Avh-1 50-60Hz
Terasaki Electric Co., Ltd.
Air Circuit Breaker
Type: Ap-20
Iec 2000A
Freq: 50-60Hz
Rule: Nk
Amb.Temp. 45°C
Ct Ratio: 2000:3
Short-time Current 70Ka 1 Sec.
Ha-6833-11-2
Poles: 3
Voltage: Ac 660V
Ta-5343-1-1
Nk (80T216)
Over-current Trip
Aor-1Cs-as
Base Cur. Io: 1600A
Ct Rating Ict: 2000/3A
S1-so: Ac100~250V
Dc100~250V
Sp-so: Dc 24V
Pqh9268B1
3 P|E|
Manual Stored |C|
Aor- 1Cs-as |A|
Ct: 2000 A
Sht Voltage Trip |A|
Ac 450 V
Aux: 5A5B |A|
Ocr Alarm: 1A |C|
Inter Lock: 1B |A|
Position Indicator:
Conn/Test 1C |A|
Ta-5360-1-5 P20
Auxiliary Sw.
Axh-1
5P3A2B
Na-6024-1-4
5P2A3B
Na-6024-2-1
Ta-4023-1-1
09503.504
Voltage Trip Device
Avh-1
Ac420~480V
Na-5977-1
Type: Anp-1C-b
Code: B42-1A/A14-1B
Swg.No: J-0262
Dwg.No: J-0151
Weight: 163.500 Kg
